Pair Flared Insulated Copper Tubing With Brass Nuts & Plastic Caps
Summary:
Insulation Flared copper tube and pipe perfectly fits every air conditioning application such as ductless mini-split, heat pump units and centralized air ducted units.
Poly Foam Pipe Insulation
|
|
Flared ending | Flared ending with plastic cap |
Air Con Pipe Sizes Available: (copper pipe sizes in mm)
| copper pipe coil | Diameter of Copper Pipe | Insulation Material | Thickness o f Insulation Layer | Copper Pipe Lengths | Ending |
 | 1/4”x Φ6.35 – 3/8”x Φ9.52 | Poly Foam Pipe Insulation (White) | 8~20mm | Set 3m, 4m, 5m, and 6m. | Both sides are flared with nuts or cap |
| 1/4”x Φ6.35 – 1/2”x Φ12.70 | |||||
| 1/4”x Φ6.35 – 5/8”x Φ15.88 | |||||
| 3/8”x Φ9.52 – 5/8”x Φ15.88 | |||||
| 3/8”x Φ9.52 – 3/4”x Φ19.05 | |||||
| 1/2”x Φ12.70 – 3/4”x Φ19.05 |
Safety:
Safety Standards
Insulated copper tube and pipe conforms to most current safety and performance standards for copper pipe and insulation.
Copper Tube/Pipe | Australian: AS/NZS 1571 U.S.A. : ASTM B280-13 France: EN 12735-1 |
Our insulation is in accordance with the standard as following:
Outside pipe insulation | Australian: AS/NZS 1530.3 U.S.A. : ASTM B280-13 France: EN1350-1 M1 |
Packaging:
1.each set will be put into the shrink film,and then be put into a single carton
2.several sets will be put into one outer carton
3.according to the customer's requirement
