Electronics Grade Clean Agent Hydrofluoroether HFE 347

Hydrofluoroether HFE-347 (1,1,2,2-tetrafluoroethyl-2,2,2-trifluoroethyl ether) has excellent inertness, high density, low viscosity, low surface tension, and Hydrofluoroether HFE-347 has excellent properties such as dielectric constant; it is non-flammable, non-toxic, non-corrosive, volatile and leaves no residue, and is widely used in solvent diluents, precision cleaning, insulating fluids, thermal cooling fluids, etc.



Structure of Hydrofluoroether HFE 347

Hydrofluoroether HFE 347 Applications Tel：+86-592-5803997





industry applications

As clean agent in semiconductor industries

HFE 347 is widely used as clean agent in semiconductor industries,

It can effectively remove organic residues, grease and other pollutants, and has excellent surface tension adjustment without causing damage to the surface of the material being cleaned. it is alternative of  3M7100/7200.

As an Anti-fingerprint thinner

Hydrofluoroether HFE 347 solvents have good compatibility with perfluoropolyethers and can be used as anti-fingerprint diluents and have good compatibility with Daikin, Shin-Etsu and PPG mother liquors.

as dry agent

Hydrofluoroether HFE 347 can be used as a dry blasting agent soaked in carbon compounds or alcohol.

as Thinner of Perfluoropolyether lubricant

Hydrofluoroether HFE347 can be used as a thinner agent of perfluoropolyether lubricant.



hFE 347 Technical Specifications & Storage



HFE347 Basic information
Product Name:	1,1,2,2-Tetrafluoroethyl 2,2,2-trifluoroethyl ether
CAS:	406-78-0
MF:	C4H3F7O
MW:	200.05
EINECS:	609-858-6
HFE347 Chemical Properties
Boiling point	50 °C
density	1.487
refractive index	1.276
Specific Gravity	1.487
CAS DataBase Reference	406-78-0(CAS DataBase Reference)
EPA Substance Registry System	HFE-347pcf2 (406-78-0)

Test items	Specifications
Appearance	Clear colorless liquid
Purity	≥99.5%
Water	≤100ppm



Packing: 20L HDPE lined steel drums, 50L HDPE lined steel drums, 200L HDPE lined steel drums

Storage: HFE 347 is shipped in a special stainless steel drum, It is to be kept in cool and dry place, without being exposed to heat source, sunlight and raining.
